| TECHNICAL SPECIFICATION |
|---|
| Model ID |
|---|
| Manufacturer (Make) | CCM |
| Model Name | C-XR230-M |
| Year | 2008 |
| Category(class) | Motocross / Dirtbike |
| Engine |
|---|
| Engine Capacity (Displacement) | 230 ccm (14.04 cubic inches) |
| Engine Type | Single cylinder |
| Bore x Stroke | Ø67.0 mm x 65.0 mm (Ø2.64 inches x 2.56 inches) |
| Bore/Stroke Ratio | 1.03 |
| Compression Ratio | 9.2:1 |
| Stroke | 4 |
| Timing System | DOHC |
| Fuel System(Carburetion) | Carburettor |
| Ignition | Electronic ignition |
| Starter System | Electric |
| Lubrication System | Wet Sump |
| Cooling System | Air |
| Powertrain |
|---|
| Transmission (Final Drive) | Chain |
| Chassis/Suspension/Brakes |
|---|
| Front Suspension | Conventional 40mm |
| Rear Suspension | Single shock - adjustable preload |
| Front Brakes | Single disc |
| Rear Brakes | Single disc |
| Dimensions |
|---|
| Seat Height | 800 mm (31.5 inches) |
| Wheelbase | 1350 mm (53.15 inches) |
| Ground Clearance | 340 mm (13.39 inches) |
| Dry Weight | 118.0 kg (260 lb) |
| Performance |
|---|
| Max Power | 18.00 HP (13.1 kW) at 8500 RPM |
| Power/Weight Ratio | 0.14 Hp/Kg |
| Top Speed | - |
| Acceleration (dart, speedup) time | |
| 0-100 km/h | 11.1 seconds |
| 0-60 mph | 10.5 seconds |
| 1/4 mile | - |
| 60 to 140 km/h, highest gear | - |
