| TECHNICAL SPECIFICATION |
|---|
| Model ID |
|---|
| Manufacturer (Make) | Ducati |
| Model Name | Multistrada 1200 |
| Year | 2011 |
| Category(class) | Sport-touring |
| Engine |
|---|
| Engine Capacity (Displacement) | 1198 ccm (73.11 cubic inches) |
| Engine Type | V2, four-stroke |
| Bore x Stroke | Ø106.0 mm x 67.9 mm (Ø4.17 inches x 2.67 inches) |
| Bore/Stroke Ratio | 1.56 |
| Compression Ratio | 11.5:1 |
| Valves per Cylinder | 4 |
| Timing System | DESMODROMIC VALVE CONTROL |
| Fuel System(Carburetion) | Injection. Tsubishi electronic fuel injection system, Mikuni elliptical throttle bodies |
| Starter System | Electric |
| Cooling System | Liquid |
| Exhaust System | Stainless steel muffler with catalytic converter and 2 lambda probes, aluminium tail pipes |
| Powertrain |
|---|
| Clutch | Light action, wet, multiplate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run |
| Gearbox | 6 speed |
| Transmission (Final Drive) | Chain |
| Chassis/Suspension/Brakes |
|---|
| Frame Type | Tubular steel Trellis frame |
| Front Suspension | Marzocchi 50mm fully adjustable usd forks |
| Rear Suspension | Progressive linkage with fully adjustable Sachs monoshock. Aluminium single-sided swingarm |
| Front Brakes | Double disc |
| Front Brakes Diameter | Ø320 mm (Ø12.6 inches) |
| Rear Brakes | Single disc |
| Rear Brakes Diameter | Ø245 mm (Ø9.65 inches) |
| Front Tire | 120/70-17 |
| Rear Tire | 190/55-17 |
| Dimensions |
|---|
| Seat Height | 850 mm (33.46 inches) |
| Fork Angle (Rake) | 25.0° degrees |
| Wheelbase | 1530 mm (60.24 inches) |
| Dry Weight | 189.0 kg (417 lb) |
| Fuel Capacity | 20.00 litres (5.28 gallons) |
| Performance |
|---|
| Max Power | 150.00 HP (109.5 kW) at 9250 RPM |
| Max Torque | 118.65 Nm (87.24 ft*lbs) at 7500 RPM |
| Power/Weight Ratio | 0.71 Hp/Kg |
| Top Speed | - |
| Acceleration (dart, speedup) time | |
| 0-100 km/h | 3.2 seconds |
| 0-60 mph | 3 seconds |
| 1/4 mile | - |
| 60 to 140 km/h, highest gear | - |
