| TECHNICAL SPECIFICATION |
|---|
| Model ID |
|---|
| Manufacturer (Make) | Harley-Davidson |
| Model Name | FXCWC Rocker C |
| Year | 2009 |
| Category(class) | Cruiser / Chopper / Custom |
| Engine |
|---|
| Engine Capacity (Displacement) | 1584 ccm (96.66 cubic inches) |
| Engine Type | V2, four-stroke |
| Bore x Stroke | Ø95.3 mm x 111.1 mm (Ø3.75 inches x 4.37 inches) |
| Bore/Stroke Ratio | 0.86 |
| Fuel System(Carburetion) | Injection. ESPFI |
| Starter System | Electric |
| Cooling System | Air |
| Exhaust System | Chrome, staggered shorty exhaust with dual mufflers |
| Powertrain |
|---|
| Clutch | 9-plate, wet |
| Gearbox | 6 speed |
| Transmission (Final Drive) | Belt |
| Chassis/Suspension/Brakes |
|---|
| Frame Type | Mild steel tubular frame; rectangular section backbone; stamped, |
| Front Suspension | Telescopic fork, 49 mm |
| Front Suspension Travel | 127 mm (5 inches) |
| Rear Suspension | Hidden, horizontal-mounted, coil-over |
| Rear Suspension Travel | 79 mm (3.11 inches) |
| Front Brakes | Single disc. 4-piston |
| Front Brakes Diameter | Ø292 mm (Ø11.5 inches) |
| Rear Brakes | Single disc. 2-piston |
| Rear Brakes Diameter | Ø292 mm (Ø11.5 inches) |
| Front Tire | 90/90-R19 |
| Rear Tire | 240/40-R18 |
| Dimensions |
|---|
| Overall Length | 2415 mm (95.08 inches) |
| Seat Height | 641 mm (25.24 inches) |
| Fork Angle (Rake) | 36.5° degrees |
| Trail | 157 mm (6.18 inches) |
| Wheelbase | 1760 mm (69.29 inches) |
| Ground Clearance | 135 mm (5.31 inches) |
| Dry Weight | 307.0 kg (677 lb) |
| Fuel Capacity | 18.90 litres (4.99 gallons) |
| Performance |
|---|
| Max Torque | 117.00 Nm (86.03 ft*lbs) at 3200 RPM |
| Top Speed | - |
| Acceleration (dart, speedup) time | |
| 0-100 km/h | - |
| 0-60 mph | - |
| 1/4 mile | - |
| 60 to 140 km/h, highest gear | - |
