| TECHNICAL SPECIFICATION |
|---|
| Model ID |
|---|
| Manufacturer (Make) | Honda |
| Model Name | DN-01 |
| Year | 2010 |
| Category(class) | All-round |
| Engine |
|---|
| Engine Capacity (Displacement) | 680 ccm (41.5 cubic inches) |
| Engine Type | V2, four-stroke |
| Bore x Stroke | Ø1,000.0 mm x 1,000.0 mm (Ø0.04 inches x 0.04 inches) |
| Bore/Stroke Ratio | 1 |
| Valves per Cylinder | 4 |
| Timing System | SOHC |
| Fuel System(Carburetion) | Injection. PGM-FI with automatic enrichment circuit, 40mm throttle bodies and 12-hole injectors |
| Starter System | Electric |
| Cooling System | Liquid |
| Powertrain |
|---|
| Transmission (Final Drive) | Shaft drive (cardan) |
| Chassis/Suspension/Brakes |
|---|
| Front Suspension | 41mm telescopic fork with 4.2 inches travel |
| Rear Suspension | Pro Arm single-side swingarm with single shock, seven-position spring preload adjustability; 4.7 inches travel |
| Front Brakes | Double disc. ABS and CBS with dual full-floating 296mm discs and three-piston calipers |
| Rear Brakes | Single disc. ABS and CBS with single 276mm disc and three-piston caliper |
| Front Tire | 130/70-ZR17 |
| Rear Tire | 190/50-ZR17 |
| Dimensions |
|---|
| Seat Height | 691 mm (27.2 inches) |
| Fork Angle (Rake) | 28.5° degrees |
| Wheelbase | 1605 mm (63.19 inches) |
| Curb Weight | 269.9 kg (595 lb) |
| Fuel Capacity | 15.14 litres (4 gallons) |
| Reserve Fuel Capacity | 3.02 litres (0.8 gallons) |
| Performance |
|---|
| Top Speed | - |
| Acceleration (dart, speedup) time | |
| 0-100 km/h | - |
| 0-60 mph | - |
| 1/4 mile | - |
| 60 to 140 km/h, highest gear | - |
