| TECHNICAL SPECIFICATION |
|---|
| Model ID |
|---|
| Manufacturer (Make) | KTM |
| Model Name | 85 SX 19/16 |
| Year | 2007 |
| Category(class) | Pocket bike / Minibike (Cross) |
| Engine |
|---|
| Engine Capacity (Displacement) | 84 ccm (5.13 cubic inches) |
| Engine Type | Single cylinder |
| Bore x Stroke | Ø47.0 mm x 49.0 mm (Ø1.85 inches x 1.93 inches) |
| Bore/Stroke Ratio | 0.96 |
| Stroke | 2 |
| Valves per Cylinder | 1 |
| Fuel System(Carburetion) | Carburettor. Keihin PWK 28 |
| Ignition | Moric digital 2M1 |
| Starter System | Kick |
| Lubrication System | Mixture lubrication 1:40 |
| Cooling System | Liquid |
| Exhaust System | Aluminium |
| Powertrain |
|---|
| Clutch | Wet multi-disc clutch, operated hydraulically |
| Gearbox | 6 speed |
| Chassis/Suspension/Brakes |
|---|
| Frame Type | Chromium molybdenum |
| Front Suspension | WP USD, 43 mm |
| Front Suspension Travel | 115 mm (4.53 inches) |
| Rear Suspension | WP monoshock PDS |
| Rear Suspension Travel | 185 mm (7.28 inches) |
| Front Brakes | Single disc |
| Front Brakes Diameter | Ø220 mm (Ø8.66 inches) |
| Rear Brakes | Single disc |
| Rear Brakes Diameter | Ø200 mm (Ø7.87 inches) |
| Front Tire | 70/100-19 |
| Rear Tire | 90/100-16 |
| Dimensions |
|---|
| Seat Height | 900 mm (35.43 inches) |
| Fork Angle (Rake) | 24.0° degrees |
| Wheelbase | 1290 mm (50.79 inches) |
| Ground Clearance | 415 mm (16.34 inches) |
| Dry Weight | 68.0 kg (150 lb) |
| Fuel Capacity | 5.00 litres (1.32 gallons) |
| Performance |
|---|
| Top Speed | - |
| Acceleration (dart, speedup) time | |
| 0-100 km/h | - |
| 0-60 mph | - |
| 1/4 mile | - |
| 60 to 140 km/h, highest gear | - |
