| TECHNICAL SPECIFICATION |
|---|
| Model ID |
|---|
| Manufacturer (Make) | Moto Guzzi |
| Model Name | 1200 Sport 4V |
| Year | 2010 |
| Category(class) | Street Fighter |
| Engine |
|---|
| Engine Capacity (Displacement) | 1151 ccm (70.24 cubic inches) |
| Engine Type | V2, four-stroke |
| Bore x Stroke | Ø95.0 mm x 81.2 mm (Ø3.74 inches x 3.2 inches) |
| Bore/Stroke Ratio | 1.17 |
| Compression Ratio | 11.0:1 |
| Valves per Cylinder | 4 |
| Timing System | OHV |
| Fuel System(Carburetion) | Injection. Multipoint sequential electronic injection, Magneti Marelli IAW 5A phased, alfa-n system; 2 x Ø50 mm throttle bodies with Weber IWP 189 injectors, Lambda probe. |
| Starter System | Electric |
| Lubrication System | Splash |
| Cooling System | Air |
| Exhaust System | Euro 3 |
| Powertrain |
|---|
| Clutch | Double disk, dry |
| Gearbox | 6 speed |
| Transmission (Final Drive) | Shaft drive (cardan) |
| Chassis/Suspension/Brakes |
|---|
| Frame Type | Tubular cradle, high tensile steel |
| Front Suspension | Telescopic hydraulic fork with Ø 45 mm spring preload and rebound damping adjustable. |
| Front Suspension Travel | 120 mm (4.72 inches) |
| Rear Suspension | Single arm suspension with progressive linkage, rear shock absorber adjustable in rebound and pre-load (hydraulic) |
| Rear Suspension Travel | 140 mm (5.51 inches) |
| Front Brakes | Double disc |
| Front Brakes Diameter | Ø320 mm (Ø12.6 inches) |
| Rear Brakes | Single disc |
| Rear Brakes Diameter | Ø282 mm (Ø11.1 inches) |
| Front Tire | 120/70-ZR17 |
| Rear Tire | 180/55-ZR17 |
| Dimensions |
|---|
| Overall Length | 2195 mm (86.42 inches) |
| Overall Height | 1160 mm (45.67 inches) |
| Seat Height | 800 mm (31.5 inches) |
| Fork Angle (Rake) | 25.0° degrees |
| Trail | 120 mm (4.72 inches) |
| Wheelbase | 1485 mm (58.46 inches) |
| Ground Clearance | 185 mm (7.28 inches) |
| Dry Weight | 240.0 kg (529 lb) |
| Fuel Capacity | 23.00 litres (6.08 gallons) |
| Reserve Fuel Capacity | 5.00 litres (1.32 gallons) |
| Performance |
|---|
| Max Power | 103.26 HP (75.4 kW) at 7000 RPM |
| Max Torque | 105.00 Nm (77.21 ft*lbs) at 6750 RPM |
| Power/Weight Ratio | 0.38 Hp/Kg |
| Top Speed | - |
| Acceleration (dart, speedup) time | |
| 0-100 km/h | 4.5 seconds |
| 0-60 mph | 4.3 seconds |
| 1/4 mile | - |
| 60 to 140 km/h, highest gear | - |
