| TECHNICAL SPECIFICATION |
|---|
| Model ID |
|---|
| Manufacturer (Make) | Moto Guzzi |
| Model Name | Stelvio 1200 4V ABS |
| Year | 2011 |
| Category(class) | Enduro |
| Engine |
|---|
| Engine Capacity (Displacement) | 1151 ccm (70.24 cubic inches) |
| Engine Type | V2, four-stroke |
| Bore x Stroke | Ø95.0 mm x 81.2 mm (Ø3.74 inches x 3.2 inches) |
| Bore/Stroke Ratio | 1.17 |
| Compression Ratio | 11.0:1 |
| Valves per Cylinder | 2 |
| Timing System | OHV |
| Fuel System(Carburetion) | Injection |
| Ignition | Multipoint sequential electronic ignition, Magneti Marelli |
| Starter System | Electric |
| Cooling System | Oil & air |
| Exhaust System | Stainless steel two-into-one |
| Powertrain |
|---|
| Clutch | Single-disc with integrated anti-vibration buffer |
| Gearbox | 6 speed |
| Transmission (Final Drive) | Shaft drive (cardan) |
| Chassis/Suspension/Brakes |
|---|
| Frame Type | Tubular in high-strength steel with integrated engine |
| Front Suspension | Upside down Ø 50 mm fully adjustable forks (spring preload and hydraulic for rebound and compression) with mounting for radial calipers. |
| Front Suspension Travel | 170 mm (6.69 inches) |
| Rear Suspension | Progressive single swingarm, fully adjustable monoshock with separate gas reservoir (spring preload and hydraulic for rebound and compression). |
| Rear Suspension Travel | 155 mm (6.1 inches) |
| Front Brakes | Double disc. Stainless steel wave discs, radial calipers with 4 opposed pistons. |
| Front Brakes Diameter | Ø320 mm (Ø12.6 inches) |
| Rear Brakes | Single disc. Single fixed stainless steel disc, floating caliper with 2 parallel pistons. |
| Rear Brakes Diameter | Ø282 mm (Ø11.1 inches) |
| Front Tire | 110/90-R19 |
| Rear Tire | 180/55-R17 |
| Dimensions |
|---|
| Overall Length | 2250 mm (88.58 inches) |
| Overall Width | 1 mm (0.04 inches) |
| Overall Height | 1475 mm (58.07 inches) |
| Seat Height | 840 mm (33.07 inches) |
| Fork Angle (Rake) | 27.0° degrees |
| Trail | 125 mm (4.92 inches) |
| Wheelbase | 1535 mm (60.43 inches) |
| Ground Clearance | 210 mm (8.27 inches) |
| Dry Weight | 251.0 kg (553 lb) |
| Fuel Capacity | 18.00 litres (4.76 gallons) |
| Reserve Fuel Capacity | 3.30 litres (0.87 gallons) |
| Performance |
|---|
| Max Power | 105.00 HP (76.6 kW) at 7500 RPM |
| Max Torque | 108.00 Nm (79.41 ft*lbs) at 6400 RPM |
| Power/Weight Ratio | 0.37 Hp/Kg |
| Top Speed | - |
| Acceleration (dart, speedup) time | |
| 0-100 km/h | 4.6 seconds |
| 0-60 mph | 4.4 seconds |
| 1/4 mile | - |
| 60 to 140 km/h, highest gear | - |
