| TECHNICAL SPECIFICATION |
|---|
| Model ID |
|---|
| Manufacturer (Make) | Moto Morini |
| Model Name | Granpasso 1200 |
| Year | 2011 |
| Category(class) | All-round |
| Engine |
|---|
| Engine Capacity (Displacement) | 1187 ccm (72.44 cubic inches) |
| Engine Type | V2, four-stroke |
| Bore x Stroke | Ø107.0 mm x 66.0 mm (Ø4.21 inches x 2.6 inches) |
| Bore/Stroke Ratio | 1.62 |
| Compression Ratio | 12.5:1 |
| Valves per Cylinder | 4 |
| Fuel System(Carburetion) | Injection. Magneti Marelli |
| Ignition | I.A.W. electronics |
| Starter System | Electric |
| Lubrication System | Forced by oil pump |
| Cooling System | Liquid |
| Exhaust System | Sport Termignoni with double silencer, 3-way catalytic converter and oxygen sensor. |
| Powertrain |
|---|
| Gearbox | 6 speed |
| Transmission (Final Drive) | Chain |
| Chassis/Suspension/Brakes |
|---|
| Frame Type | High-strength steel tube trellis frame |
| Front Suspension | Marzocchi upside down fork |
| Front Suspension Travel | 175 mm (6.89 inches) |
| Rear Suspension | Ohlins single shock absorber |
| Rear Suspension Travel | 200 mm (7.87 inches) |
| Front Brakes | Double disc. Floating disc, 2-piston |
| Front Brakes Diameter | Ø298 mm (Ø11.73 inches) |
| Rear Brakes | Single disc |
| Rear Brakes Diameter | Ø255 mm (Ø10.04 inches) |
| Front Tire | 110/80-R19 |
| Rear Tire | 150/70-R17 |
| Dimensions |
|---|
| Overall Length | 2170 mm (85.43 inches) |
| Overall Width | 850 mm (33.46 inches) |
| Seat Height | 875 mm (34.45 inches) |
| Fork Angle (Rake) | 26.5° degrees |
| Trail | 135 mm (5.31 inches) |
| Wheelbase | 1505 mm (59.25 inches) |
| Ground Clearance | 200 mm (7.87 inches) |
| Dry Weight | 210.0 kg (463 lb) |
| Fuel Capacity | 27.00 litres (7.13 gallons) |
| Reserve Fuel Capacity | 5.50 litres (1.45 gallons) |
| Performance |
|---|
| Max Power | 118.00 HP (86.1 kW) at 8500 RPM |
| Max Torque | 103.60 Nm (76.18 ft*lbs) at 7000 RPM |
| Power/Weight Ratio | 0.5 Hp/Kg |
| Top Speed | - |
| Acceleration (dart, speedup) time | |
| 0-100 km/h | 3.7 seconds |
| 0-60 mph | 3.5 seconds |
| 1/4 mile | - |
| 60 to 140 km/h, highest gear | - |
