| TECHNICAL SPECIFICATION |
|---|
| Model ID |
|---|
| Manufacturer (Make) | Peugeot |
| Model Name | TKR 50 |
| Year | 2006 |
| Category(class) | Scooter |
| Engine |
|---|
| Engine Capacity (Displacement) | 49 ccm (2.99 cubic inches) |
| Engine Type | Single cylinder |
| Stroke | 2 |
| Fuel System(Carburetion) | Carburettor |
| Starter System | Electric & kick |
| Cooling System | Air |
| Powertrain |
|---|
| Transmission (Final Drive) | Shaft drive (cardan) |
| Chassis/Suspension/Brakes |
|---|
| Front Brakes | Single disc |
| Front Brakes Diameter | Ø190 mm (Ø7.48 inches) |
| Rear Brakes | Expanding brake (drum brake) |
| Rear Brakes Diameter | Ø110 mm (Ø4.33 inches) |
| Front Tire | 120/90-10 |
| Rear Tire | 130/90-10 |
| Dimensions |
|---|
| Overall Length | 1760 mm (69.29 inches) |
| Overall Width | 670 mm (26.38 inches) |
| Overall Height | 1000 mm (39.37 inches) |
| Dry Weight | 81.0 kg (179 lb) |
| Fuel Capacity | 6.10 litres (1.61 gallons) |
| Performance |
|---|
| Top Speed | - |
| Acceleration (dart, speedup) time | |
| 0-100 km/h | - |
| 0-60 mph | - |
| 1/4 mile | - |
| 60 to 140 km/h, highest gear | - |
