| TECHNICAL SPECIFICATION |
|---|
| Model ID |
|---|
| Manufacturer (Make) | Suzuki |
| Model Name | DR-Z125 |
| Year | 2011 |
| Category(class) | Enduro |
| Engine |
|---|
| Engine Capacity (Displacement) | 124 ccm (7.57 cubic inches) |
| Engine Type | Single cylinder, four-stroke |
| Bore x Stroke | Ø57.0 mm x 48.8 mm (Ø2.24 inches x 1.92 inches) |
| Bore/Stroke Ratio | 1.17 |
| Compression Ratio | 9.5:1 |
| Timing System | SOHC |
| Fuel System(Carburetion) | Carburettor. Mikuni™ VM20SS |
| Ignition | Digital-type CDI |
| Starter System | Kick |
| Lubrication System | Wet sump |
| Cooling System | Air |
| Powertrain |
|---|
| Gearbox | 5 speed |
| Transmission (Final Drive) | Chain |
| Chassis/Suspension/Brakes |
|---|
| Front Suspension | Telescopic, coil spring, oil damped |
| Rear Suspension | Link type, coil spring, oil damped |
| Front Brakes | Single disc |
| Rear Brakes | Expanding brake (drum brake) |
| Front Tire | 70/100-19 |
| Rear Tire | 90/100-16 |
| Dimensions |
|---|
| Overall Length | 1885 mm (74.21 inches) |
| Overall Width | 770 mm (30.31 inches) |
| Seat Height | 805 mm (31.69 inches) |
| Wheelbase | 1270 mm (50 inches) |
| Ground Clearance | 290 mm (11.42 inches) |
| Curb Weight | 89.0 kg (196 lb) |
| Fuel Capacity | 4.80 litres (1.27 gallons) |
| Performance |
|---|
| Top Speed | - |
| Acceleration (dart, speedup) time | |
| 0-100 km/h | - |
| 0-60 mph | - |
| 1/4 mile | - |
| 60 to 140 km/h, highest gear | - |
