| TECHNICAL SPECIFICATION |
|---|
| Model ID |
|---|
| Manufacturer (Make) | Triumph |
| Model Name | Street Triple 675 |
| Year | 2008 |
| Category(class) | Street Fighter |
| Engine |
|---|
| Engine Capacity (Displacement) | 675 ccm (41.19 cubic inches) |
| Engine Type | In-line three |
| Bore x Stroke | Ø74.0 mm x 52.3 mm (Ø2.91 inches x 2.06 inches) |
| Bore/Stroke Ratio | 1.41 |
| Compression Ratio | 12.7:1 |
| Stroke | 4 |
| Timing System | DOHC |
| Fuel System(Carburetion) | Injection. Multipoint sequential electronic fuel injection |
| Ignition | Digital - inductive type - via electronic engine management system |
| Starter System | Electric |
| Cooling System | Liquid |
| Powertrain |
|---|
| Clutch | Wet. multi-plate |
| Gearbox | 6 speed |
| Transmission (Final Drive) | Chain |
| Chassis/Suspension/Brakes |
|---|
| Frame Type | Aluminum beam twin spar |
| Front Suspension | 41mm upside down forks |
| Rear Suspension | Monoshock with adjustable preload |
| Front Brakes | Double disc |
| Front Brakes Diameter | Ø308 mm (Ø12.13 inches) |
| Rear Brakes | Single disc |
| Rear Brakes Diameter | Ø220 mm (Ø8.66 inches) |
| Front Tire | 120/70-ZR17 |
| Rear Tire | 180/55-ZR17 |
| Dimensions |
|---|
| Overall Length | 2029 mm (79.88 inches) |
| Overall Width | 780 mm (30.71 inches) |
| Overall Height | 1250 mm (49.21 inches) |
| Seat Height | 803 mm (31.61 inches) |
| Fork Angle (Rake) | 24.3° degrees |
| Trail | 95 mm (3.74 inches) |
| Wheelbase | 1394 mm (54.88 inches) |
| Dry Weight | 166.5 kg (367 lb) |
| Fuel Capacity | 17.41 litres (4.6 gallons) |
| Performance |
|---|
| Max Power | 107.00 HP (78.1 kW) at 11700 RPM |
| Max Torque | 51.00 Nm (37.5 ft*lbs) at 9100 RPM |
| Power/Weight Ratio | 0.57 Hp/Kg |
| Top Speed | - |
| Acceleration (dart, speedup) time | |
| 0-100 km/h | 3.3 seconds |
| 0-60 mph | 3.2 seconds |
| 1/4 mile | - |
| 60 to 140 km/h, highest gear | - |
