| TECHNICAL SPECIFICATION |
|---|
| Model ID |
|---|
| Manufacturer (Make) | Triumph |
| Model Name | Tiger |
| Year | 2008 |
| Category(class) | All-round |
| Engine |
|---|
| Engine Capacity (Displacement) | 1050 ccm (64.08 cubic inches) |
| Engine Type | Twin |
| Bore x Stroke | Ø79.0 mm x 71.4 mm (Ø3.11 inches x 2.81 inches) |
| Bore/Stroke Ratio | 1.11 |
| Compression Ratio | 12.0:1 |
| Stroke | 4 |
| Timing System | DOHC |
| Fuel System(Carburetion) | Injection. Multipoint sequential electronic fuel injection |
| Ignition | Digital - inductive type - via electronic engine management system |
| Starter System | Electric |
| Cooling System | Liquid |
| Powertrain |
|---|
| Clutch | Wet. multi-plate |
| Gearbox | 6 speed |
| Transmission (Final Drive) | Chain |
| Chassis/Suspension/Brakes |
|---|
| Frame Type | Aluminum beam perimeter |
| Front Suspension | 43mm upside down forks with adjustable preload. rebound and compression damping |
| Rear Suspension | Monoshock with adjustable preload and rebound damping |
| Front Brakes | Double disc |
| Front Brakes Diameter | Ø320 mm (Ø12.6 inches) |
| Rear Brakes | Single disc |
| Rear Brakes Diameter | Ø255 mm (Ø10.04 inches) |
| Front Tire | 120/70-ZR17 |
| Rear Tire | 180/55-ZR17 |
| Dimensions |
|---|
| Overall Length | 2111 mm (83.11 inches) |
| Overall Width | 841 mm (33.11 inches) |
| Overall Height | 1321 mm (52.01 inches) |
| Seat Height | 833 mm (32.8 inches) |
| Fork Angle (Rake) | 23.2° degrees |
| Trail | 88 mm (3.46 inches) |
| Wheelbase | 1509 mm (59.41 inches) |
| Dry Weight | 197.8 kg (436 lb) |
| Fuel Capacity | 19.68 litres (5.2 gallons) |
| Performance |
|---|
| Max Power | 114.00 HP (83.2 kW) at 9400 RPM |
| Max Torque | 74.00 Nm (54.41 ft*lbs) at 6250 RPM |
| Power/Weight Ratio | 0.51 Hp/Kg |
| Top Speed | - |
| Acceleration (dart, speedup) time | |
| 0-100 km/h | 3.6 seconds |
| 0-60 mph | 3.4 seconds |
| 1/4 mile | - |
| 60 to 140 km/h, highest gear | - |
