| TECHNICAL SPECIFICATION |
|---|
| Model ID |
|---|
| Manufacturer (Make) | Triumph |
| Model Name | Tiger |
| Year | 2009 |
| Category(class) | Sport |
| Engine |
|---|
| Engine Capacity (Displacement) | 1050 ccm (64.08 cubic inches) |
| Engine Type | In-line three, four-stroke |
| Bore x Stroke | Ø79.0 mm x 71.4 mm (Ø3.11 inches x 2.81 inches) |
| Bore/Stroke Ratio | 1.11 |
| Valves per Cylinder | 4 |
| Timing System | DOHC |
| Fuel System(Carburetion) | Injection. Multipoint sequential electronic fuel injection |
| Ignition | --) |
| Starter System | Electric |
| Cooling System | Liquid |
| Powertrain |
|---|
| Clutch | Wet. multi-plate |
| Gearbox | 6 speed |
| Transmission (Final Drive) | Chain |
| Chassis/Suspension/Brakes |
|---|
| Frame Type | Aluminium beam twin spar |
| Front Suspension | Showa 43mm upside down forks with adjustable preload. rebound and compression damping. 150mm travel |
| Rear Suspension | Showa Monoshock with adjustable preload and rebound damping 150mm rear wheel travel |
| Front Brakes | Double disc |
| Front Brakes Diameter | Ø320 mm (Ø12.6 inches) |
| Rear Brakes | Single disc |
| Rear Brakes Diameter | Ø255 mm (Ø10.04 inches) |
| Front Tire | 120/70-ZR17 |
| Rear Tire | 180/55-ZR17 |
| Dimensions |
|---|
| Overall Length | 2110 mm (83.07 inches) |
| Overall Width | 840 mm (33.07 inches) |
| Overall Height | 1320 mm (51.97 inches) |
| Seat Height | 835 mm (32.87 inches) |
| Fork Angle (Rake) | 23.2° degrees |
| Wheelbase | 1510 mm (59.45 inches) |
| Dry Weight | 198.0 kg (437 lb) |
| Fuel Capacity | 20.00 litres (5.28 gallons) |
| Performance |
|---|
| Max Power | 113.98 HP (83.2 kW) at 9400 RPM |
| Max Torque | 100.00 Nm (73.53 ft*lbs) at 6250 RPM |
| Power/Weight Ratio | 0.51 Hp/Kg |
| Top Speed | - |
| Acceleration (dart, speedup) time | |
| 0-100 km/h | 3.6 seconds |
| 0-60 mph | 3.4 seconds |
| 1/4 mile | - |
| 60 to 140 km/h, highest gear | - |
