| TECHNICAL SPECIFICATION |
|---|
| Model ID |
|---|
| Manufacturer (Make) | Yamaha |
| Model Name | FZ6 ABS |
| Year | 2007 |
| Category(class) | Street Fighter |
| Engine |
|---|
| Engine Capacity (Displacement) | 600 ccm (36.61 cubic inches) |
| Engine Type | In-line four |
| Bore x Stroke | Ø65.5 mm x 44.5 mm (Ø2.58 inches x 1.75 inches) |
| Bore/Stroke Ratio | 1.47 |
| Compression Ratio | 12.2:1 |
| Stroke | 4 |
| Timing System | DOHC |
| Fuel System(Carburetion) | Injection |
| Ignition | TCI |
| Starter System | Electric |
| Lubrication System | Wet sump |
| Cooling System | Liquid |
| Powertrain |
|---|
| Clutch | Wet, multiple-disc |
| Transmission (Final Drive) | Chain |
| Chassis/Suspension/Brakes |
|---|
| Frame Type | Aluminium die-cast, diamond shaped |
| Front Suspension | Telescopic forks |
| Front Suspension Travel | 130 mm (5.12 inches) |
| Rear Suspension | Swingarm (monocross) |
| Rear Suspension Travel | 130 mm (5.12 inches) |
| Front Brakes | Double disc |
| Front Brakes Diameter | Ø298 mm (Ø11.73 inches) |
| Rear Brakes | Single disc |
| Rear Brakes Diameter | Ø245 mm (Ø9.65 inches) |
| Front Tire | 120/70-ZR17 |
| Rear Tire | 180/55-ZR17 |
| Dimensions |
|---|
| Overall Length | 2095 mm (82.48 inches) |
| Overall Width | 755 mm (29.72 inches) |
| Overall Height | 1085 mm (42.72 inches) |
| Seat Height | 795 mm (31.3 inches) |
| Wheelbase | 1440 mm (56.69 inches) |
| Ground Clearance | 145 mm (5.71 inches) |
| Dry Weight | 185.0 kg (408 lb) |
| Fuel Capacity | 19.40 litres (5.13 gallons) |
| Performance |
|---|
| Max Power | 76.43 HP (55.8 kW) |
| Max Torque | 51.60 Nm (37.94 ft*lbs) at 5270 RPM |
| Power/Weight Ratio | 0.37 Hp/Kg |
| Top Speed | - |
| Acceleration (dart, speedup) time | |
| 0-100 km/h | 4.6 seconds |
| 0-60 mph | 4.4 seconds |
| 1/4 mile | - |
| 60 to 140 km/h, highest gear | - |
