| TECHNICAL SPECIFICATION |
|---|
| Model ID |
|---|
| Manufacturer (Make) | Yamaha |
| Model Name | YZ 250 |
| Year | 2008 |
| Category(class) | Motocross / Dirtbike |
| Engine |
|---|
| Engine Capacity (Displacement) | 249 ccm (15.19 cubic inches) |
| Engine Type | Single cylinder |
| Bore x Stroke | Ø66.4 mm x 72.0 mm (Ø2.61 inches x 2.83 inches) |
| Bore/Stroke Ratio | 0.92 |
| Compression Ratio | 9.2:1 |
| Stroke | 2 |
| Ignition | CDI |
| Cooling System | Liquid |
| Powertrain |
|---|
| Gearbox | 5 speed |
| Transmission (Final Drive) | Chain |
| Chassis/Suspension/Brakes |
|---|
| Front Suspension | Speed-Sensitive System inverted fork |
| Front Suspension Travel | 300 mm (11.81 inches) |
| Rear Suspension | Fully adjustable single shock, 12.4-in travel |
| Front Brakes | Single disc |
| Front Brakes Diameter | Ø250 mm (Ø9.84 inches) |
| Rear Brakes | Single disc |
| Rear Brakes Diameter | Ø245 mm (Ø9.65 inches) |
| Front Tire | 80/80-M21 |
| Rear Tire | 110/90-M19 |
| Dimensions |
|---|
| Overall Length | 2177 mm (85.71 inches) |
| Overall Width | 828 mm (32.6 inches) |
| Overall Height | 1306 mm (51.42 inches) |
| Seat Height | 993 mm (39.09 inches) |
| Fork Angle (Rake) | 26.0° degrees |
| Wheelbase | 1481 mm (58.31 inches) |
| Ground Clearance | 381 mm (15 inches) |
| Dry Weight | 96.2 kg (212 lb) |
| Fuel Capacity | 7.94 litres (2.1 gallons) |
| Performance |
|---|
| Top Speed | - |
| Acceleration (dart, speedup) time | |
| 0-100 km/h | - |
| 0-60 mph | - |
| 1/4 mile | - |
| 60 to 140 km/h, highest gear | - |
